dsh-visual-plugin

dsh-visual-plugin

<p align="center"> <img src="https://raw.githubusercontent.com/jyh20030112/dsh-visual-plugin/main/assets/deepseek_neon_pixel_whale_transparent.svg" width="240" alt="DeepSeek neon pixel whale"> </p>

<p align="center"> <a href="https://www.npmjs.com/package/dsh-visual-plugin"><img src="https://img.shields.io/npm/v/dsh-visual-plugin?logo=npm&label=npm" alt="npm version"></a> <a href="https://www.npmjs.com/package/dsh-visual-plugin"><img src="https://img.shields.io/npm/dm/dsh-visual-plugin?label=downloads" alt="npm downloads"></a> <a href="https://github.com/jyh20030112/dsh-visual-plugin/stargazers"><img src="https://img.shields.io/github/stars/jyh20030112/dsh-visual-plugin?logo=github&label=Stars" alt="GitHub stars"></a> <a href="https://github.com/jyh20030112/dsh-visual-plugin/blob/main/LICENSE"><img src="https://img.shields.io/badge/license-MIT-65a30d?style=flat" alt="MIT license"></a> <br> <img src="https://img.shields.io/badge/TypeScript-3178C6?style=flat&logo=typescript&logoColor=fff" alt="TypeScript"> <img src="https://img.shields.io/badge/zero__runtime__deps-16a34a?style=flat" alt="zero runtime deps"> </p>

<p align="center"> Give your text-only model eyes: forward user images to any OpenAI-compatible vision model and see the results in a Web UI right panel. </p>

<p align="center"> <a href="README.md"><b>English</b></a> · <a href="README.zh.md">简体中文</a> </p>

A plugin for DeepSeek Harness.

Features

• Automatic description — the wrapper adapter recursively describes uploaded images and image-bearing tool results in a model-bound copy while the visible chat keeps the originals.
• In-conversation lifecycle cards — automatic analysis appears immediately below its source image and settles in place as success or failure; one logical analysis produces one card.
• Intent-aware prompts — send an image with a question and the description is generated from your own words.
• vision_describe tool — the model can answer a later follow-up question when the automatic description lacks the requested detail.
• Right-side panel — configure endpoint / model / key, test the connection, watch one latest description per image with thumbnails (2s auto-refresh), read remaining balance.
• Secrets stay secret — the API key lives in the harness credentials seam (write-only, never echoed).

How it works

<p align="center"> <img src="https://raw.githubusercontent.com/jyh20030112/dsh-visual-plugin/main/assets/vision-bridge-flow.svg" width="720" alt="Animated demo of the vision bridge in dsh web: the user sends an image, the vision bridge auto-describes it, and the main model answers from the description"> </p>

image in composer or tool result → wrapper finds it at any content depth → visible message keeps the image
  → adapter stream → readImage → vision API → "[视觉描述] …" in the private model request only
  → text-only model answers → /vision-bridge/recent → panel thumbnail + description (2s poll)

Unconfigured or failed calls degrade to a [视觉描述失败] <reason> placeholder, so the conversation never breaks.

Quick start

dsh plugin --profile web add dsh-visual-plugin   # or: github:jyh20030112/dsh-visual-plugin

When developing this checkout against a local DeepSeek Harness source tree, install the local package instead:

cd /absolute/path/to/dsh-visual-plugin
npm run bootstrap
dsh plugin --profile web add link:/absolute/path/to/dsh-visual-plugin

bootstrap automatically finds a sibling or ancestor-adjacent Harness checkout. For another layout, set its location explicitly:

HARNESS=/absolute/path/to/deepseek-harness npm run bootstrap

Restart dsh web, then:

1. Open Settings → Plugins → Plugin configuration and expand the Vision Bridge card:

   <img src="https://raw.githubusercontent.com/jyh20030112/dsh-visual-plugin/main/assets/vision-bridge-config.png" width="560" alt="Vision Bridge configuration card in the settings plugin configuration tab">

2. Fill in the endpoint URL, the vision model name, and the API key. The 侧边栏 / Sidebar toggle shows or hides the image-history panel; the history limit defaults to 20, and leaving it empty means unlimited. Click 保存 / Save, then 测试连接 / Test connection.

3. In the model picker, select provider DeepSeek (Vision) — the plugin's wrapper adapter declares image input so the gateway admits uploads.

4. Send an image (optionally with a question). The model answers from the generated description, and the image-history panel shows the thumbnail + description within ~2s.

Reference local model

This project is developed and tested with a locally deployed Empero AI Qwythos-9B as the vision backend. Its SGLang deployment can expose an OpenAI-compatible /v1 endpoint; enter the endpoint URL and the server's registered model name (for example, Qwythos) in the Vision Bridge panel. The plugin is not tied to Qwythos-9B and can use any compatible vision model.

Uninstall

dsh plugin --profile web remove dsh-visual-plugin

Restart dsh web. The command forwards to pnpm remove inside the profile, and the bundle layer list reconciles to drop the plugin automatically.

Project layout

src/
  index.ts      host plugin: vision orchestration + vision_describe + HTTP routes
  vision.ts     OpenAI-compatible vision calls (describe / test / balance)
  model-messages.ts  model-bound image rewrite + per-attachment cache
  description-policy.ts  intent-first prompt + low-information retry
  config.ts     settings namespace `vision-bridge` + schema
  adapter.ts    deepseek-vision wrapper adapter (admission + private rewrite boundary)
  client/       browser half: panel / sidebar toggle / automatic + tool cards / locales / css
cordis.patch.yml  bundle patch layer

Build

npm run bootstrap && npm run typecheck && npm run build   # needs a local harness checkout

Prebuilt lib/ is committed, so consumers never build.

CI/CD

ci.yml verifies artifacts and the pack contents on every push/PR. release.yml (tag v*) checks the version, packs, creates a GitHub Release, and publishes to npm.

Resources

• DeepSeek Harness — the plugin host this project extends.
• Qwythos-9B on Hugging Face — the local vision model used for development and testing.
• awesome-dsh-plugin — the curated DSH plugin list where this plugin is registered.

Thanks

• HsiangNianian — for their help and insights during development.
• tingfeng347 — for the build-stability and local-harness-setup fixes.
• dsh-auto-continue — a DSH Web UI plugin that auto-resumes interrupted requests with 「继续」 (error classification, adaptive backoff, browser notifications); a handy companion.

License

MIT
